1.Dual Color Mould，IP67 Protection Level
2.Hot-swappable Battery，Longer time Battery Endurance
3.Wide Temperature range，-20 to 60 °
4.Windows10/11 Home, IoT or Pro
5.Support BT、WIFI、GPS、4G/5G、2D、RJ45, RS232
6.FHD 1920*1200，800nits visible in Sunlight
7.Precise Location
Specification | CPU | Intel® Processor N-series，N100/N150/N305 Up to 3.4/3.6GHZ |
OS | Win10/11 Home IoT or Pro | |
Memory | 8GB+128GB/up to 2TB | |
Screen | 10inch LCD screen, Resolution 800*1280 /1200*1920 optional | |
Brightness | 500/800 nit/1000 nit optional | |
Touch Panel | 10point touch 7H （Customized anti-glare/glove touch/wet hand touch) | |
2G/3G/4G/5G | LTE FDD: B1/B3/B5/B7/B8/B20； LTE TDD: B38/B40/B41； WCDMA: B1/B5/B8； GSM: B3/B8 | |
WIFI | 802.11a/b/g/n/ac/ax、 Frequency2.4G/5.8G/6G | |
Bluetooth | Bluetooth 5.3 (BLE) class1 Distance：10m | |
Location | GPS、Beidou、Galileo、GLONASS（1 from 4choices）U-Blox M8N | |
Camera | Front 5.0MP+Rear 8.0MP， Auto-focus LED | |
I/O | AUDIO * 1/Φ 3.5mm standard headphone jack | |
*1，Type-C USB3.0 Support OTG | ||
*1，Type-A USB3.0 | ||
MINI HDMI*1 | ||
*1，RJ45， 1000Mbps | ||
DC *1，12V/4A | ||
12Pin Pogo Pin *1 | ||
SIM card slot * 1 | ||
TF card slot * 1, supporting a maximum of 256GB | ||
Aviation plug * 2, (can be customized: car power supply, network port, serial port and other functions) | ||
Button | Built-in buttons | Power on/off button * 1, volume+-, custom button F/P |
Optional Modules | GNSS | Domestic single Beidou/RTK high-precision positioning/other customized modules |
Fingerprint | Standard fingerprint module/supports public security fingerprints/FBI fingerprints | |
NFC&LF/HF | Supports standard protocols such as 14443A/14443B/15693/125K/customization of HF and other special modules | |
Ultra-high frequency | PR9200， Distance 1:3-5 meters:R2000, Distance 2:10-15M meters | |
ID card | Second generation offline ID card module | |
Scanner | Optional 1D zebra SE655/2D zebra SE2707 QR code module/customized types of scanning modules like N1 | |
Battery Parameters | Capacity | Main Battery: 5000mAh，7.6v lithium- ion battery，Removable，endurance 8h（1080P Video + LCD, 50% Brightness）Support hot Plug Hot-Swappable Sub-Battery: 800mAh ，7.6v lithium- ion battery |
Battery life | 8 hours (default 50% volume, playing 1080P local high-definition video) | |
Dimension | Whole machine | 277.48*182.74*21.5，1150g ， black |
Reliability | adapter | AC100V~240V/Output DC12V/4A |
Operating Temperature | -20 °C ~ 60 °C | |
Storage temperature | -30 °C ~ 70 °C | |
Humidity | 95% non condensing | |
Protective characteristics | IP67 | |
Drop height | 1.2-meter drop resistant composite wood floor | |
Software | Certification | CE, IP67、ROHS、UN38.3、MSDS, EMC、3C, Ex-proof,energy-saving, MIL-STD-810H |
